LAN Modular Plug RJ45 8P8C Cat 6 UTP/STP
Description:
Cat 6 8P8C, Unshielded Twisted Pair and Shielded Twisted Pairs, is low-cost and high efficient connector for LAN/DATA cables for termination. High quality material, art-of design and workship make high stability and reliability. Comply with FCC/IEC/UL/POE/RoHS and REACH, suitable for all LAN/DATA cable in NIC, switch, router, Hub, server and so on.
Features:
● Comply with ANSI/TIA-568.2-D & ISO/IEC 11801
● Suitable for 4PPoE (IEEE802.3bt / IEC60512-99-002) Applications
● Comply with requirements of ANSI/TIA-1096-A (FCC Part 68)
● Comply with IEC 60603-7 series for RJ45 8-way connector
● Comply with UL 1863
Specification:
•Electrical Characteristics
|
UL Application |
250 Volts AC max, AT AMP |
|
Dielectric Withstanding Voltage |
500 Volts AC |
|
Insulation Resistance |
100MΩ |
|
Termination |
Resistance 20MΩ max after environmental testing |
•Mechanical characteristics
|
Insertion Life |
750 mating cycles |
|
Installation Temperature |
0/50℃ |
|
Operation & Storage Temperature |
-20/60℃ |
|
Tensile Strength Cable to Plug |
20pound(min) |
|
Pulling Force |
10N(max) |
•Parts List
|
House Body |
Polycarbonate, UL94V-2 or UL94V-0 |
|
Gold Plating |
50u", 30u", 15u", 6u", 3u" or flash |
|
Contact Blade |
Copper Alloy |
|
Contact |
Stranded or Solid Wire, from 24 AWG to 26AWG |
|
Color |
Transparent or other color |
Application
● LAN cable termination
● Switch, Router, Hub, NIC, Server
Order Information
|
Spec. |
Packing Rate (pcs) |
N.W(KG) |
G.W(KG) |
Packing Quantities |
Carton Size(CM) |
|
Cat 6 8P8C UTP |
10,000 |
15.20 |
16.40 |
1,000pcs/bag, 2 inner boxes/CTN |
52*36*32 |
|
Cat 6 8P8C STP |
10,000 |
24.5 |
25.50 |
1,000pcs/bag, 2 inner boxes/CTN |
52*36*32 |
* Package can be specified according to customers requirements.
* Parts and parameter are subject to change without prior notice.
