Telephone Modular Plug RJ11 4P2C/6P2C/6P4C/6P6C for Cat 3 Cable
Description:
Cat 3 4P2C/6P2C/6P4C/6P6C, is low-cost and high efficient connector for telephone and POTS cables for termination. High quality material, art-of design and workship make high stability and reliability, suitable for 1-pair round telephone cable in handset, DTMF and digital VOIP telephone.
Features:
● Meet FCC Standard
● Different Gold Thickness Available (50u",30u",15u",6u",3u" , flash)
● Mating Cycles: Up to 1200 Times
● Suitable for 4PPoE (IEEE802.3bt / IEC60512-99-002) Applications
● Cable Wire Gauge : 24AWG to 26AWG
● UL / POE+ / CE Certified & Comply with RoHS & REACH
● With Special Designed Boot
Specification:
•Electrical Characteristics
|
UL Application |
250 Volts AC max, AT AMP |
|
Dielectric Withstanding Voltage |
500 Volts AC |
|
Insulation Resistance |
100MΩ |
|
Termination |
Resistance 20MΩ max after environmental testing |
•Mechanical characteristics
|
Insertion Life |
750 mating cycles |
|
Installation Temperature |
0/50℃ |
|
Operation & Storage Temperature |
-20/60℃ |
|
Tensile Strength Cable to Plug |
20pound(min) |
|
Pulling Force |
10N(max) |
•Parts List
|
House Body |
Polycarbonate, UL94V-2 or UL94V-0 |
|
Gold Plating |
50u", 30u", 15u", 6u", 3u" or flash |
|
Contact Blade |
Copper Alloy |
|
Contact |
Stranded or Solid Wire, from 24 AWG to 26AWG |
|
Color |
Transparent or other color |
Application
● Telephone cable termination
● Handset, DTMF telephone, POTS, VOIP
Order Information
|
Spec. |
Packing Rate (pcs) |
N.W(KG) |
G.W(KG) |
Packing Quantities |
Carton Size(CM) |
|
4P2C plug UTP |
25,000 |
16.63 |
17.77 |
1,000pcs/bag, 2 inner boxes/CTN |
50*36*27 |
|
4P4C plug UTP |
25,000 |
17.03 |
18.17 |
1,000pcs/bag, 2 inner boxes/CTN |
50*36*27 |
|
6P2C plug UTP |
25,000 |
16.38 |
17.52 |
1,000pcs/bag, 2 inner boxes/CTN |
50*36*27 |
|
6P4C plug UTP |
25,000 |
16.38 |
17.52 |
1,000pcs/bag, 2 inner boxes/CTN |
50*36*27 |
|
6P6C plug UTP |
20,000 |
17.24 |
18.38 |
1,000pcs/bag, 2 inner boxes/CTN |
50*36*27 |
* Package can be specified according to customers requirements.
* Parts and parameter are subject to change without prior notice.
